Magnet Specifications

Below is the main materials we supply
Br (Gauss) bHc (Oersted) iHc (Oersted) BH Max (MGO) Magnetising Force (Oersted) AlNiCo 2 7,200 500 525 1.55 3,000 AlNiCo 3 7,000 475 500 1.4 2 ,000 AlNi Co 4 5,500 720 750 1.35 2,000 AlNiCo 5 12,600 650 663 5.4 3,000 AlNiCo 6 11,500 750 750 4 .5 3,000 AlNiCo 8 9,000 1,600 1,625 5.6 6,250 AlNiCo 9 11,000 1 , 500 1,580 10.5 8 ,000
Click here for Alnico full MDS

Ceramic

Br (Gauss) bHc (Oersted) iHc (Oersted) BH Max (M GO) Magnetising Force (Oersted) Ceramic 1 2,200 1,700 2,750 1.0 7,500 Ceramic 5 4,000 2,000 2,300 3.5 10,000 Ceramic 8 3,700 2,800 3,250 3.3 10,000 Ceramic 8C 4,300 2,500 2,550 4.3 10,000
Click here for Ceramic full MDS

Neodymium

Br (Gauss) bHc (Oersted) iHc (Oersted) BH Max (MGO) Magnetising Force (Oersted) N30 11,600 10,000 11,000 30 30,000 N30H 11,600 10,000 11,000 30 30,000 N30SH 11,600 10,000 11,000 30 30,000 N35 12,000 10,900 12,000 35 30,000 N35H 12,000 10,900 12,000 35 30,000 N35SH 12,000 10,900 12,000 35 30,000 N38 12,300 11,300 12,000 38 30,000 N38H 12,300 11,300 12,000 38 30,000 N38SH 12,300 11,300 12,000 38 30,000 N40 12,750 11,400 12,000 40 30,0 00 N40H 12,750 11,400 12,000 40 30,000 N40SH 12,750 11,400 12,000 40 30,000 N42 13,100 10,900 12,000 42 30,000 N45 13, 2 00 11,300 12,000 45 30,000 N48 13,800 10,500 11,000 48 30,000
Click here for Neodymium full MDS

Samarium Cobalt

Br (Gauss) bHc (Oersted) iHc (Oersted) BH Max (MGO) Magnetising Force (Oersted) SmCo5 - 18MGO 8,800 8,800 18 ,000 18 25,000 SmCo5 - 20MGO 9,100 8,800 15,000 20 25,000 Sm2Co17 - 24MGO 10,000 9,000 15,000 24 43,500 Sm2Co17 - 26MGO 10,400 9,500 15,000 26 43,500 Sm2Co17 - 28MGO 10,800 9,500 15,000 28 43,500 Sm2Co17 - 30MGO 11,000 9,500 15,000 30 43,000
Click here for Samarium Cobalt full MDS
